Universal Busbars

Advanced Conversion provides convenient Universal Buses that allow the design engineer to select a standard Power Ring for their DC Link (capacitance and voltage) and easily connect it to their a desired switch module.

It’s always a challenge at the initial design stage to test the switch module performance with various gate driver and DC Link options.

The Universal buses enable a fast setup for bench testing.

1. 1. Decide what continuous operating bus voltage you will be using.
   2. Scroll through the Standard Power Ring DC Link products and select the appropriate capacitance size and voltage.
   3. Lastly, match the Standard product spec selected with the switch modules listed on the page below.
   4. You need to order the DC Link capacitor and the Universal Bus separately. The combination is predesigned to bolt together easily.

If you do not see your desired switch module listed, or have specific connection needs, please reach out to our team using the information below.

We are continually working with the switch module suppliers to add more Universal Bus options to our list. Additionally, custom busbar solutions that connect to our standard capacitors are available with minimal NRE and MOQ.

For an ever more optimized solution, visit our Customized Capacitor Solutions page.

Examples of standard products that should fit your needs are available below. Most are available in stock either direct or at one of our distributors.

Check our Standard Test Kits page for integrated DC Link Cap/Bus products that are co-designed with the Switch Module Suppliers.

If one is available for your Switch selection, it might be the better choice than taking the time and expense to make your own bus.
