HIGH-TEMPERATURE DC LINK CAPACITORS
Advanced Conversion has partnered with W. L. Gore & Associates to provide high-temperature film capacitors for operation up to 200°C while retaining long life and capacitance stability. These capacitors are offered in standard sizes ranging from 30μF to 100μF.
Please refer to the 803 Part Series datasheet for information. Custom sizes and configurations are available.
Visit High-Temperature DC-Link – Overview page for more details.
For more information, please contact Hannah Fishman, Customer Service Manager.
Advanced Conversion acquired the rights to all the SBE technology and products, including the datasheets.
Please reach out to check stock availability and prices for your desired quantity. We accept Credit Cards, PayPal, ACH, wire, or company checks for payment.
In addition to the standard products below, we specialize in the design, development, and manufacturing of application-specific products (non-standard capacitance values, tight tolerance, specific form factors, etc.) as well as high-performance integrated modules.
Advanced Conversion’s standard product offering includes:
- DC Link Capacitors
- Universal Test kits for DC Link Capacitors
- Test kits for the Infineon HP Drive 6 Pack IGBT Module
- Test kits for various semi modules
- Infineon IGBT module test kits
- Pulse/High Voltage Capacitors
POWER RING FILM CAPACITOR – DC LINK CAPACITORS
Design/Application Notes:
Power Ring Film Capacitor patented technology offers industry-leading power density and ESL/ESR performance in a compact package. These products are designed for long-term exposure to elevated temperatures, continuous thermal cycles, and transportation vibration.
For more information, read our application notes “Mounting Instructions for Standard Power Rings”.
If you need some assistance in selecting the appropriate Power Ring for your needs, please contact Dr. Michael Brubaker, CTO.
| DC Volt (Vdc) | CAP. (μF) | Standard Part # | Nominal Case Outside Diameter | Nominal Overall Height | RMS Current at 85°C |
|---|---|---|---|---|---|
| 450 | 500 | 700D529 (pdf) | 4.57″ (116.1 mm) | 2.04″ (51.8 mm) | 115 |
| 450 | 800 | 700D600 (pdf) | 6.27″ (159.3 mm) | 2.16″ (54.9 mm) | 225 |
| 450 | 1,600 | 700D601 (pdf) | 8.47″ (215.2 mm) | 2.16″ (54.9 mm) | 400 |
| 600 | 500 | 700D652* (pdf) | 6.27″ (159.3 mm) | 2.05″ | 210 |
| 600 | 500 | 700D349 (pdf) | 6.27″ (159.3 mm) | 2.16″ (54.9mm) | 210 |
| 600 | 1,000 | 8.47″ (215.2 mm) | 2.16″ (54.9mm) | 400 | |
| 600 | 1,500 | 700D523 (pdf) | 10.52″ (267.2 mm) | 2.16″ (54.9 mm) | 460 |
| 700 | 500 | 700D717* (pdf) | 6.27″ (159.3 mm) | 2.05″ (52.1 mm) | 175 |
| 700 | 500 | 700D599 (pdf) | 6.27″ (159.3 mm) | 2.16″ (54.9mm) | 175 |
| 700 | 1,000 | 700D547 (pdf) | 8.47″ (215.2 mm) | 2.16″ (54.9mm) | 300 |
| 900 | 215 | 700D651* (pdf) | 6.27″ (159.3 mm) | 2.05″ (52.1 mm) | 175 |
| 900 | 215 | 700D406 (pdf) | 6.27″ (159.3 mm) | 2.16″ (54.9 mm) | 175 |
| 900 | 425 | 700D407 (pdf) | 8.47″ (215.2 mm) | 2.16″ (54.9 mm) | 285 |
| 900 | 1,000 | 700D525 (pdf) | 10.0″ (254 mm) | 2.72″ (69.1 mm) | 300 |
| 900 | 1,500 | 700D509 (pdf) | 12.33″ (313.2 mm) | 2.82″ (71.7 mm) | 380 |
| 1,100 | 1,000 | 700D628 (pdf) | 10.0″ (254 mm) | 2.72″ (69.1 mm) | 235 |
| 1,100 | 1,500 | 700D590 (pdf) | 12.33″ (313.2 mm) | 2.82″ (71.7 mm) | 300 |
| 1,200 | 115 | 700D718* (pdf) | 6.27″ (159.3 mm) | 2.05″ (52.1 mm) | 155 |
| 1,200 | 115 | 700D408 (pdf) | 6.27″ (159.3 mm) | 2.16″ (54.9 mm) | 155 |
| 1,200 | 225 | 700D409 (pdf) | 8.47″ (215.2 mm) | 2.16″ (54.9 mm) | 265 |
| 1300 | 1,000 | 700D643 (pdf) | 12.33″ (313.2 mm) | 2.82″ (71.7 mm) | 300 |
| 1,500 | 75 | 700D719* (pdf) | 6.27″ (159.3 mm) | 2.05″ (52.1 mm) | 140 |
| 1,500 | 75 | 700D410 (pdf) | 6.27″ (159.3 mm) | 2.16″ (54.9 mm) | 140 |
| 1,500 | 140 | 700D411 (pdf) | 8.47″ (215.2 mm) | 2.16″ (54.9 mm) | 250 |
*This part has terminal feet that face inward.
EVALUATION PARTS WITH THERMOCOUPLES
All of the above parts can be shipped with embedded Thermocouples (TC)s for direct measurement as powered. TCs are of type K and have 3ft leads.
Please inquire about drawings for TC placement within the capacitor assembly.
EVALUATION TEST KITS
We offer test kits to match up with many popular switching module choices and we are adding more all the time. If you don’t see the one you are looking for, please reach out to us at [email protected].
UNIVERSAL BUSBARS
Universal Busbars are designed to connect an Advanced Conversion Power Ring Film Capacitor to some of the industry’s leading Si and SiC “half bridge” switching devices. The universal bus bars offer a low inductance solution for anyone looking to interface an Advanced Conversion Power Ring into their system.
Note that even lower inductance solutions are possible with customized Integrated Solutions.
| Universal Busbar PN | Compatible Discrete Power Rings | Compatible Switching Devices |
|---|---|---|
| Bus-1195 | 700D601 | Microsemi
MSCSM170AM058CD3AG |
| Bus-1196 | 700D601 | Infineon FF2MR12KM1
FUJI 2MSI300VAH-120C-53 Wolfspeed WAB300M12MB3 ABB 5SNG 0300Q170300 Microsemi APTGT200A120G |
| Bus-1197 | 700D600 (pdf) | Infineon FF2MR12KM1
FUJI 2MSI300VAH-120C-53 Wolfspeed WAB300M12MB3 ABB 5SNG 0300Q170300 Microsemi APTGT200A120G |
| Bus-1207 | 700D601 | CMT-PLA3SB12340A
CXT-PLA3SA12340A CXT-PLA3SA123450A CXT-PLA3SA123550A
|
TEST KITS FOR VARIOUS SEMI MODULES
DC Link Capacitor for Hitachi RoadPakTM
Advanced Conversion is now offering an optimized DC link for easy evaluation of the Hitachi RoadPakTM module. This fully integrated DC link with a laminated bus provides optimal connection directly to the half-bridge modules and DC input. Features include:
- Low inductance (<6nH) allows for fast switching.
- Low ESR (600μOhm nominal) for minimized capacitor losses.
- 900V rating supports up to 250kW inverter applications.
Please refer to the 700A386 Data Sheet (pdf) for more information.
For more information, please contact Dr. Michael Brubaker.
Cissoid SiC Intelligent Power Modules (IPMs)
Together with NAC Semi, Advanced Conversion has created a series of high-performance DC Link Capacitors that mechanically integrate into the Cissoid SiC Intelligent Power Modules (IPMs). These capacitors offer low ESL and low ESR for fast-switching SiC transistors and for high power density. They also come with the option to mount the devices flexibly onto the IPM.
Capacitor assembly with integrated busbar tightly fit to Cissoid IPM’s.
-
- 906A115, 906A117, 700A360, and 700A361
- Thermocouple options available
Universal busbar with connections for Cissoid IPM’s
-
- Bus-1207
For datasheet downloads, please contact NAC Semi.
INFINEON 6 PACK MODULE TEST KITS
Power Ring Test Kits are available for different Power Ring part numbers and with high-performance bus structure and adapter plate for popular IGBT modules from Infineon, Semikron, Fuji, Danfoss, Microsemi, OnSemiconductor, Hitachi, ABB, Cissoid. ESL presented to the switch module terminals is typically 6 – 8 nH.
Test kits for the Infineon HP Drive & OnSemi VE-Trac Direct IGBT Module:
| DC Volt. (Vdc) | CAP. (µF) | Test kit # | Vertical or Horizontal | Operating Temperature (°C) |
|---|---|---|---|---|
| 500 | 500 | 700A186 (pdf) | Horizontal | 105°C |
| 500 | 500 | 700A373 (pdf) | Vertical | 105°C |
| 500 | 500 | 700A243 (pdf) | Horizontal | 105°C |
| 750 | 260 | 700A245 (pdf) | Horizontal | 105°C |
| 750 | 320 | 906A105 (pdf) | Horizontal | 125°C |
| 900 | 135 | 906A104 (pdf) | Horizontal | 125°C |
*IGBT modules sold separately by other distributors.
STANDARD BOX CAP REPLACEMENT
Advanced Conversion is now offering replacements for many types of “box capacitors” for High Voltage DC Link and Pulse Capacitors.
Using our well-known ring capacitor approach, the product offering fits on the same footprint as many popular capacitor offerings and has the same terminal connection system. But it offers the following benefits to the traditional box cap approach:
-
- Lighter weight
- Higher pulse capability
- Longer life
- Lower Trise in the DC Link application
- Usually a shorter lead time of 15 – 20 weeks
- Usually lower prices due to lower manufacturing costs
Please refer to the 700D722 Data Sheet (pdf) for more information, as an example.
We can likely supply the capacitor you need. Just contact our customer service.
PULSED POWER
The Power Ring’s patented technology offers extreme energy storage/pulse power density in an innovative smaller package that allows for modularity and mounting flexibility.
This dry film, environmentally clean technology, is designed with terminals/interconnect systems that result in the lowest available ESL and peak discharge currents in excess of 250,000 amps.
| DC Volt. (Vdc) | CAP. RANGE (µF) | Series/Standard Part # | Height | Diameter Range | Peak Current Range (kA) |
|---|---|---|---|---|---|
| 750 | 500 – 5,000 | 771D | 3.35″ (85 mm) | 4.9″ – 13.6″ (126 – 352 mm) | 5.6 – 56 |
| 750 | 1,000 | 771D102 | 3.35″ (85 mm) | 6.5″ (165 mm) | 12 |
| 750 | 5,000 | 771D104 | 3.35″ (85 mm) | 13.9″ (352 mm) | 56 |
| 750 | 2,500 | 771D105 | 3.35″ (85 mm) | 10″ (255 mm) | 28 |
| 750 | 650 | 771D120 | 3.35″ (85 mm) | 5.4″ (138 mm) | 7 |
| 1,500 | 500 – 3,000 | 772D | 6.10″ (155 mm) | 6.5″ – 15″ (165 – 380 mm) | 11 – 69 |
| 1,500 | 3,000 | 772D102 | 6.10″ (155 mm) | 15″ (380 mm) | 69 |
| 2,500 | 100 – 1,000 | 773D | 5.00″ (127 mm) | 5.25″ – 15″ (137 – 380 mm) | 6.7 – 68 |
| 2,500 | 1,000 | 773D103 | 5.00″ (127 mm) | 14.84″ (377 mm) | 68 |
| 2,500 | 500 | 773D104 | 5.00″ (127 mm) | 10.7″ (272 mm) | 34 |
| 2,500 | 100 | 773D105 (pdf) | 5.00″ (127 mm) | 5.25″ (137mm) | 10 |
| 3,500 | 100 – 650 | 774D | 6.23″ (158 mm) | 5.75″ – 13.7″ (146 – 368 mm) | 10 – 68 |
| 3,500 | 100 | 774D103 | 6.23″ (158 mm) | 5.97″ (152 mm) | 10 |
| 3,500 | 140 | 774D107 | 6.23″ (158 mm) | 6.65″ (170 mm) | 14 |
| 3,500 | 650 | 774D108 | 6.23″ (158 mm) | 13.7″ (350 mm) | 66 |
| 8,000 | 5-50 | 775D | 3.35″ (85 mm) | 4.5″ – 14″ (115 mm – 355 mm) | 5.8-10 |
| 8,000 | 5 | 775D104 (pdf) | 3.35″ (85 mm) | 4.70″ (119.7 mm) | 10 |
| 8,000 | 10 | 775D103 (pdf) | 3.35″(85 mm) | 6.35″ (161.3 mm) | 20 |
| 8,000 | 17 | 775D102 (pdf) | 3.35″ (85 mm) | 8.50″ (215.9 mm) | 34.5 |
| 8,000 | 50 | 3.35″ (85 mm) | 14.07″ (355 mm) | 100 |
*Clocked terminals
